OSG official account. This feed features some of our latest cutting tool innovations. Brand mascot: Tap-kun
@osgtapkun
Please visit our homepage for inquiries.
OSG’s custom carbide drill optimized for high-speed drilling in aluminum application at an astonishing feed rate of 15,000 mm/min.
Details:
#drilling
#aluminum
#OSGCorporation
CM-RMS peripheral cutting edge type ceramic end mill for high-speed machining at high temperatures, with roughing efficiency surpassing carbide end mills.
Brand new ADO-50D coolant-through carbide drill for ultra-efficiency in deep-hole drilling applications. Watch it in action: ADO-50D in SCM420H, DC 5 mm, H 250 mm, Vc 60 m/min, n 3,822 min-1, Vf 764 mm/min, f 0.2 mm/rev.
#drilling
#ADO50D
#osgcorporation
#osgtools
OSG Corporation is an official partner of San-en NeoPhoenix, a B. League professional basketball team based in the central region of Japan. Thank you for the 2022-23 season 🏀
#OSGLife
#LifeAtOSG
#オーエスジー
#三遠ネオフェニックス
#B
リーグ
#SANENNEOPHOENIX
#BLEAGUE
Dia. 5.5 mm ADO-20D high performance coolant-fed carbide drill in SCM440 (30 HRC). New sizes for 8xD, 10xD, 15xD, 20xD and 30xD have been added this April.
#drilling
#osgcorporation
#osgtools
Carbide end mill with chipbreakers. Chipbreakers are notched profiles along the cutting edge that break down long chips into small and manageable pieces. This configuration is especially ideal for users who seek uninterrupted machining capability.
#milling
#chipbreakers
#AEVML
Dia. 8 mm ADO-30D in FCD600.
The ADO is a high performance coolant-fed carbide drill series designed to excel in a variety of steels up to 50 x diameter without pecking.
Product Details:
#drilling
#osgcorporation
#osgtools
Part 6/8. Collaboration project with Genetec Corporation () on the milling of a Koppori. SUS304; Tool used for outer finishing – OSG FX-RR-EBD dia.18 mm R12.5 at n 2,652 min-1, Vf 795 mm/min, ap 0.7 mm, ae 0.7 mm; CAD/CAM: Mastercam. Machine: HERMLE C42.
MECT 2023 ⚙️
この度はご多忙の中、ポートメッセなごやにて開催されましたMECT 2023にご来場いただきまして誠にありがとうございました🙇♂️
Thank you for visiting us at MECT 2023.
We hope to see you again soon💫
#MECT2023
#MECT2023
は面白い
#オーエスジー
ADO-TRS ‘Triple Revolution’ 3-flute through-coolant carbide drill with ultra-machining efficiency in a wide range of materials. Watch it in action: Dia. 14 mm ADO-TRS in S50C with MQL. Vc 100 m/min, n 2,275 min-1, Vf 1,365 mm/min, f 0.6 mm/rev.
#osgcorporation
#osgtools
#mfg
Counterboring - Dia. 35 mm PZAG counterbore cutter (straight shank) with XP8030 inserts in S50C. Vc 150 m/min, n 1,364 min-1, Vf 272 mm/min, f 0.2 mm/rev, H 20 mm, pilot hole dia. 18 mm, air blow.
#PZAG
#indexable
#milling
#osgcorporation
#osgtools
Test run. A-POT M3 x 0.5 in A5052. The A-Tap series includes the A-SFT spiral taps for blind holes and the A-POT point taps for through holes.
#threading
#osgcorporation
#osgtools
ADF: multi-purpose carbide flat drill series for inclined surfaces and counterboring applications. Dia. 10 mm ADF-2D in action. New sizes have been recently added for the ADFLS-2D (long shank) in 0.1 mm increment. Details:
#osgcorporation
#osgtools
OSG GmbH collaborated with Gebr. Märklin & Cie. GmbH, a German toy company and milled a 1:87 scale steam locomotive made of aluminum, which was displayed at AMB 2022 in Germany and also at JIMTOF 2022 in Japan.
OSG GmbH recently completed a video documenting the project🎥
Long flute AE-VML anti-vibration carbide end mill series ideal for stainless steel, carbon steel and alloy steels. High-speed side milling is made possible by the large thick core design of the long flute AE-VML.
#AEVML
#milling
#osgcorporation
#osgtools
AE-CPR4-H long neck corner radius carbide end mill for high-efficiency and high precision milling in high-hardness steels.
Work Material: STAVAX(52 HRC)
Process: Semi-roughing
Cooperation: Roku-Roku Sangyou, Ltd.
#milling
#osgcorporation
#オーエスジー #オーエスジー株式会社
A-XPF High-efficiency and Multi-purpose Forming Tap
Outstanding durability even when machining small-diameter threads in martensitic stainless steel.
A-XPF M1 x 0.25 2P
Drill Hole Size: Φ0.91 × 3.5 mm (Blind Hole)
Tapping Length: 2 mm
Cutting Speed: 10m/min(3,183min-1)
